Description

Flush Floor Cut-In Box Kit with Brass Cover and Dual Flip Lids

Meta description: Flush-to-floor cut-in box kit with solid brass cover and two flip lids. Includes tamper-resistant duplex receptacle, gasketed components, and Arlington NM94 and NM95 cable connectors. 1-gang. cULus listed.

TL;DR – Who This Is For

Electricians and contractors installing flush floor power in finished interiors where a brass cover, minimal profile, and included receptacle simplify retrofit or cut-in applications.

Institutional Fit

– Office and conference room floor power retrofits
– Residential finished floors requiring a flush appearance
– Retail and hospitality interiors with exposed floor outlets
– Projects needing a compact 1-gang floor box with included device

Technical Specifications

Part Number	FLB3532MB
Product Type	Flush floor cut-in box kit
Trade Size	1-gang
Cover Style	Brass cover with two flip lids
Material	Brass cover
Color	Brass
Receptacle	15A tamper-resistant duplex receptacle included
Weight	1.010 lbs each
Dimensions	3.995 in x 3.995 in
UPC	018997480170
Unit Packaging	1 pc

Regulatory Compliance

– cULus listed
Install in accordance with local electrical code requirements for floor box installations.

Durability and Lifecycle

Solid brass cover provides long-term durability and a premium finish suitable for high-traffic interior floors. Flush-to-floor design reduces trip hazards while flip lids allow controlled access to power when needed.

Procurement Notes

– Designed for cut-in installations in finished floors
– Includes connectors and receptacle to reduce field sourcing
– Brass finish suited for visible interior applications
– Sold as a complete kit

What’s Included

– (1) Brass cover with two flip lids
– (1) Floor box
– (1) Gasket support plate
– (1) Gasket
– (1) 15A tamper-resistant duplex receptacle
– (1) Arlington NM95 cable connector
– (1) Arlington NM94 cable connector
– (3) #8 x 1/2 in screws
– (1) #6 x 1/2 in screw

FAQ

Is this box designed to sit flush with the finished floor?

Yes. It is designed to be flush to the floor after installation.

Does the kit include a receptacle?

Yes. A 15A tamper-resistant duplex receptacle is included.

How many flip lids does the cover have?

The brass cover includes two flip lids.

Is this suitable for retrofit installations?

Yes. It is a cut-in style box intended for finished floors.

Where can I find detailed specifications?

Click here for spec sheet
