4″ Slim Recessed Downlight 5CCT (Wet location)

**ON SPECIAL **

Description

DE45CCTW——

Downloads:

• 5CCT Slim (Wet Rated) Slim Spec sheet
• Dimming Compatibility List

Product Features:

• IC Rated
• Airtight
• 5CCT
• Suitable for Wet Locations
• Install Directly Under Joists, Maximum Layout Flexibility
• Comes with Junction Box & Driver, No Housing Required
• Fast & Easy To Install

 Specifications:

LED Type:	SMD2835
Voltage In:	120V AC
Frequency:	60Hz
Power:	9W
Lumens:	680-750lm
Power Factor:	≥0.9
CRI:	>80
Colour Temperature:	3000K/3500K/4000K/5000K/6000K
Lifespan:	50,000 hrs
Beam Angle:	110°
Dimmable:	Yes
Dimming Range:	10%-100%
Cut Hole:	4¼” (108mm)

Junction Box

Input

Volt:	100-130VAC
60Hz
PF:	>0.9

Output

Volt:	27-42VDC
Amp:	200-220MA
Pout:	9-12W
