Fortpro F229074 NTA Air Brake Compression Elbow Fitting – 1/2″ Tube x 1/2″ NPT Male, 45°, 5-Pack

Description

Specifications

• Product Line: Brakes
• Category Name: Air Brake NTA Fittings
• Part Type: NTA Male Elbow Connector
• Alternate Part Name: D.O.T. Air Brake Compression NTA Elbow Connector
• OEM Part Number: 1374-8D
• Application Type: Trailers, Semi-Trucks, Heavy Duty Trucks
• VMRS Code: 013-010-297
• Material: Brass
• Connection Type: Male Thread – Compression Fitting
• Connector Shape: Elbow
• Fitting Angle: 45 deg.
• Pipe Thread Size: 1/2 in.
• Tube Outside Diameter: 1/2 in.
• Maximum Operating Pressure: 158 psi
• Net Weight: 0.2327 lb.

Intended ApplicationFor use in connecting main or secondary air lines in the air brake system on semi-trailers, trailers, buses and agricultural machinery.
Cross-references

• 017888, 1374-8D, 13748D, 177.14748D, 17714748D, 38155, M-4371, M4371, S779AB-8-8, S779AB88
