Description
Specifications
- Product Line: Brakes
- Category Name: Air Brake Valves
- Part Type: Check Valve
- Alternate Part Name: Air One-Way Check Valve, Air Line Check Valve, One-Way Valve, Air Check Valve
- Model: SC-1
- OEM Part Number: 227870, 800373
- Application Type: Heavy Duty Trucks, Semi-Trucks
- Body Type: Straight
- Delivery Port Size: 3/8-18 NPT (Male)
- Supply Port Size: 3/8-18 NPT (Female)
- Material: Brass
- Maximum Operating Temperature: 250 deg. F (121 deg. C)
- Minimum Operating Temperature: -40 deg. F (-40 deg. C)
- Net Weight: 0.52 lb.
Intended Application
- One-way check valve used in air brake systems to allow air flow in one direction and prevent flow in the opposite direction.
- Main applications:
- Air brake systems in commercial vehicles
- Separation of air circuits.
- Applications in air suspension systems
Cross-references
- 10200 3/8, 170.227870, 227870, 5396-KN23010, 5396KN23010, 800373, EBN227870N, EM40650, KN23010, KN23010X, LCV-4065, LCV4065, R955227870N
