Fortpro SS1200-Style System Saver Air Dryer – Freightliner-Compatible Unit, Replaces R955205 (F224677)

Description

Specifications

• Product Line: Brakes
• Category Name: Air Dryers
• Part Type: Air Brake Dryer
• Model: SS-1200 (System Saver)
• OEM Part Number: R955205
• Application Type: Heavy Duty Trucks, Semi-Trucks
• Body Mounting Type: 1/2-13 UNC-2B (3x)
• Cartridge Thread Type: M39 x 1.5-6H RH
• Cartridge Type: Standard
• Control Port Size: 1/4 in.-18 NPT
• Delivery Port 1 Size: 1/2-14 NPT
• Heater Connector Type: Metri-Pack Sealed Connector (Male)
• Lower Mounting Bracket Type: 1/2-13 UNC-2B (3X) Flange Mount
• Purge Exhaust Port Type: Standard
• Purge Valve Type: Soft Seat
• Supply Port Size: 1/2 in.-14 NPT
• Minimum Operating Temperature: -40 deg. F (-40 deg. C)
• Operating Voltage: 12V
• Safety Valve Opening Pressure: 140 psi
• Thermostat Power Rating (Watts): 100W

Intended ApplicationFor use in standard air brake applications on trucks, tractors, and buses
Cross-references

• 065691, 170955205, 170955205WOC, 26QE433, 3915282, 4006110500, 800887, R955205, R955205NX, R955205X, S-13728, TDA-R955205
