Description
Specifications
- Product Line: Suspension
- Category Name: Air Springs and Bags
- Part Type: Rolling Lobe Air Spring
- Alternate Part Name: Air Bag Suspension, Suspension Air Bag, Pneumatic Spring, Air Ride Spring, Rolling Lobe Air Spring, Reversible Sleeve Air Spring, Air Suspension Bag
- OEM Part Number: W01-358-8755
- Application Type: Heavy Duty Trucks, Semi-Trucks
- VMRS Code: 016-008-000
- Material: Fiber reinforced rubber bellows
- Air Inlet Inside Thread: 1/4-18 NPT
- Air Inlet Outside Thread: 3/4 16 UNF
- Body Diameter: 10.12 in.
- Bottom Plate Alignment: Parallel
- Bottom Plate Diameter: 10.20 in.
- Bottom Plate Stud: 1/2-13 UNC
- Mounting Stud Configuration – Bottom: 4
- Mounting Stud Configuration – Top: 2
- Piston Height: 5.60 in.
- Piston Material Type: Steel
- Top Plate Diameter: 10.30 in.
- Air Spring Type: 1T Reversible Sleeve
- Collapsed Length: 7.30 in.
- Extended Length: 18.50 in.
- Net Weight: 26.45 lb.
Intended Application
- Compatible with Hendrickson Trailer (HK190T) and Hendrickson Trailer Prototype Rear Air Suspension Systems.
Cross-references
- 101015S522, 1R13124, 3528755, 566CT64397, 64397, 8522, 8755, AB1DK25B8755, AS8755, FAS-0771, FAS0771, FS8755, S22045, W013588755, 1R13-124, W01-358-8755
