Description
Specifications
- Product Line: Suspension
- Category Name: Chassis & Suspension
- Part Type: Equalizer Bushing Assembly
- Alternate Part Name: Equalizer Rebushing Kit, Equalizer Bushing Assembly
- OEM Part Number: E-2003
- Application Type: Semi-Trucks, Heavy Duty Trucks
- Outside Diameter (O.D.): 3-3/8 in.
- Material: Rubber
- Distance Between Bolt Holes: 1-3/8 in.
- Inside Diameter (ID): 3/4 in.
- Overall Length: 3-15/16 in.
- Net Weight: 4.14 lb.
Bill Of Material
- (1) Equalizer Bushing
- (2) Hex Bolt 5/8-14 UNF x 6 in. Long
- (2) Lock Hex Nut 5/8-14 UNF
- (1) Lock Tab Washer
Intended Application
- Compatible with Hutchens Four Spring Suspension H/CH 7600/9600 7700/9700 TWS, 54-1/2″ 57-1/2″ Axle Spacing, Hutchens Four Spring Suspension H/CH 7600/9600, 49″ Axle Spacing, Hutchens Four Spring Suspension H/CH 7600/9600 7700/9700 TWS, 61″ 81″ Axle Spacing, Hutchens Four Spring Suspension H/CH 7700/9700 TWS, 97″-121″ Axle Spacing, Hutchens Four Spring Suspension H/CH 7700US/9700US, Underslung, Hutchens Four Spring Suspension H/CH 7700/9700, 42-1/2″, 44″, 49″, 50″ Axle Spacing, Great Dane Model “H”.
- Always compare with your OEM part number prior to purchase to confirm full compatibility.
Cross-references
- 25756, 334341, 382003, 66905, E-2003, E2003, H1075, H77ABW, M1451, M15083, R302003, REY0751000, SP1009, TRK5541, 334-341
