RP76-L010MR-CY6T4L-TP Photoelectric Sensor for Industrial Detection

Description

Type:

RP76 Photoelectric

Shape:

Rectangular

Housing Material:

Glass Fiber reinforced plastic

Operating Voltage:

20-240 V AC/DC

Photo Type:

Retro-Reflective

Sensing Range:

10 m

Output Type:

SPST Relay

Output Function:

LO/DO selectable

Max Current:

3 A

Current Consumption:

<2 VA

Overload Trip Point:

–

Response Time:

40 ms

Connection:

Terminal Chamber

Connector:

–

Operating Temperature:

0 C – +55 C

IP Rating:

IP66

EMC Rating:

IEC 60947-5-2, Parts 7.2.6.1.2.3 or RFI>3V/m(in30-1000MHZ), ETF>1KV, ESD>4KV(contact)

Shock/Vibration Rating:

IEC 60947-5-2, Part 7.4.2 (10-55HZ, 1mm amplitude in x,y and z directions for 30 min)/IEC-60947-5-2 Part 7.4.1 (30 g, 11 ms in x, y, and z directions for six times

Short Circuit Protected:

No

Reverse Polarity Protected:

No

Weld Field Immune:

No

Lens Material:

Acrylic

Indicator LEDs:

Power: Yellow Output: Green Margin: Red

Time Options:

No Delay, On Delay, Off Delay, One Shot selectable via switch

Description:

RP76 Photoelectric, Retro-Reflective, 20-240 V AC/DC, SPST Relay, LO/DO selectable, Terminal Chamber
