Description
Specifications
- Product Line: Suspension
- Category Name: Chassis & Suspension
- Part Type: Adjustable Torque Rod
- Alternate Part Name: Torque Rod, Torque Arm Adjustable, Adjustable Torque Arm without Bushings
- OEM Part Number: 1517201
- Applicable Bushing: 10.099
- Application Type: Semi-Trucks, Heavy Duty Trucks
- Bolt Hole Diameter: 1 in.
- Mounting Position: Rear Suspension
- Torque Rod Style: Adjustable
- Material: Forged Steel
- Bushing Type: Hollow (Bushings Not Included)
- Center Bar Outside Diameter (O.D.): 1-15-32 in.
- Distance Between Bolt Holes: 15 in. to 17 in.
- Net Weight: 11.94 lb.
Bill Of Material
- Torque Rod (1)
- Bolts: (2) Hex Head Cap Screws, 5/818 UNF x 3″ Long (Grade 8).
- Lock Nut (2)
Intended Application
- Compatible with Reyco Granning 21AR Air Suspension, Reyco Granning 21B Cast Four Spring Suspension, Reyco Granning 21B Fabricated Four Spring Suspension Models. Compatible with Watson & Chalin MS2500 Series Suspensions.
- Always compare with your OEM part number prior to purchase to confirm full compatibility.
Cross-references
- 15172-01, 1517201, 345-199, 345199, E-3283A, E3283A, IT3283A, R303283A, T5485, TR001
