Description
Specifications
- Product Line: Suspension
- Category Name: Air Springs and Bags
- Part Type: Rolling Lobe Air Spring
- Alternate Part Name: Reversible Sleeve Air Spring, Rolling Lobe Air Spring, Air Ride Spring, Air Suspension Bag, Air Bag Suspension, Suspension Air Bag, Pneumatic Spring
- OEM Part Number: S-25319
- Application Type: Heavy Duty Trucks, Semi-Trucks
- VMRS Code: 016-008-000
- Material: Fiber reinforced rubber bellows
- Air Inlet Inside Thread: 1/4-18 NPT
- Air Inlet Outside Thread: 3/4 16 UNF
- Bottom Plate Alignment: Parallel
- Bottom Plate Diameter: 10.24 in.
- Bottom Plate Stud: 1/2-13 UNC
- Mounting Stud Configuration – Bottom: 4
- Mounting Stud Configuration – Top: 2
- Piston Height: 6.00 in.
- Piston Material Type: Steel
- Top Plate Diameter: 11.31 in.
- Air Spring Type: 1T Reversible Sleeve
- Collapsed Length: 7.50 in.
- Extended Length: 24.10 in.
- Net Weight: 31.15 lb.
Intended Application
- Compatible with Utility, Great Dane, Wabash, Vanguard, Hyundai Translead, and Stoughton Trailers equipped with Hendrickson INTRAAX (AANT/AANL/AAT/AAL Series) Trailer Air Suspension Systems.
Cross-references
- 1R14-152, 1R14152, 75269, 755150, S-25319, S25319
