Description
Specifications
- Product Line: Brakes
- Category Name: Slack Adjusters
- Part Type: Automatic Slack Adjusters
- Model: Haldex Style / AA1
- OEM Part Number: 40010212
- Anchor Bracket Type: Plate & Flat Stud
- Application Type: Heavy Duty Trucks, Semi-Trucks
- Compatible Brake Chamber Sizes: T-30 Std or T-16/T-24 Long Stroke
- Clevis Type: Unclevised
- Material: Alloy Steel
- Arm Bushing Inside Diameter: 1/2 in.
- Arm Length Position 1: 6 in.
- Arm Offset: No Offset
- Body Inclination Angle: 0 deg.
- Slack Spline Count: 28
- Slack Spline Diameter: 1-1/2 in.
- Grease Fitting Location: 180 deg.
- Maximum Operating Temperature: 158 deg. F (70 deg. C)
- Maximum Torque: Less than 15 foot pounds
- Minimum Operating Temperature: (-40 deg. F) (-40 deg. C)
- Operation Type: Tension Adjuster – Torque
Cross-references
- 1332841, 289312, 28931213, 400-10212, 40010212, 5662, E-6918A, E-6942, E6918A, E6942, M807013, MK42106S, R806013A
