Description
This is the heavy-duty cast version of the standard stamped steel clutch. It’s a beast for 14″ flat flywheels, packing 950 ft-lbs of torque and a 2800 lb plate load. The EZ Pedal design saves your leg, and the 8-spring ceramic disc provides superior grip. Direct replacement for Eaton 107342-24
Specifications
- Product Line: Transmission
- Category Name: Clutch Components
- Part Type: Clutch Assembly
- Alternate Part Name: Clutch Assemblies, Medium Duty Clutch Assembly
- OEM Part Number: 1076864
- Application Type: Semi-Trucks
- Clutch Diameter: 14 in.
- Flywheel Bore Diameter: 7 in.
- Spline Count: 10
- Spline Diameter: 2 in.
- Material: Steel, Ceramic Pad
- Adjustment System: Manual
- Clutch Technology: EZ Pedal ™ (Easy Pedal)
- Disc Facing Material: Ceramic
- Disc Paddle Type: 4
- Disc Spring Quantity: 8
- Pressure Plate Clamp Load: 2.800 lb.
- Torque Rating: 950 ft-lb
- Transmission Type: Manual
- Net Weight: 125 lb.
Intended Application
- Compatible with medium- to heavy-duty (Class 6-8) diesel trucks equipped with 2 in. x 10 spline input shaft manual transmissions and 14 in. flat flywheel systems, designed for engines within an approximate torque range up to 950 ft-lb, geared towards regional haul, vocational, heavy-duty delivery, utility, and municipal operations where greater thermal capacity, wear resistance, and structural durability are required in frequent stop-start cycles, but not intended for severe high-torque line-haul configurations.
- Always compare with your OEM part number prior to purchase to confirm full compatibility.
Cross-references
- 10734224, 1076864, CLU1076864, MAF-107342-24, MAF
