Fortpro 1-1/2″ Automatic Slack Adjuster – 10-Tooth, 5.5″ Bendix-Style Arm (Replaces 065170) | F224751

Description

Specifications

• Product Line: Brakes
• Category Name: Slack Adjusters
• Part Type: Automatic Slack Adjusters
• Model: Bendix Style / ASA-5
• OEM Part Number: 65170
• Application Type: Heavy Duty Trucks, Semi-Trucks
• Compatible Brake Chamber Sizes: T-16, T-24
• Clevis Type: Straight
• Clevis/Yoke Type: Easy-On (EO)
• Material: Alloy Steel
• Arm Length Position 1: 5-1/2 in.
• Arm Offset: No Offset
• Body Inclination Angle: 0 deg.
• Clevis Thread Diameter: 5/8-18 UNF-2B
• Slack Spline Count: 10
• Slack Spline Diameter: 1-1/2 in.
• Lubrication Fitting Type: 45 deg. Elbow
• Maximum Operating Temperature: 158 deg. F (70 deg. C)
• Maximum Torque: 20.000 In./Lbs.
• Minimum Operating Temperature: (-40 deg. F) (-40 deg. C)
• Operation Type: Tension Adjuster – Torque

Cross-references

• 065170, 135.1031, 1351031, 135S1031A, 40020239, 5661, 65170, E6924B, K041870, M808022, MK41100S, R806022A
