Specifications
- Product Line: Suspension
- Category Name: Air Springs and Bags
- Part Type: Rolling Lobe Air Spring
- Alternate Part Name: Air Bag Suspension, Suspension Air Bag, Rolling Lobe Air Spring, Air Ride Spring, Pneumatic Spring, Reversible Sleeve Air Spring, Air Suspension Bag
- OEM Part Number: W01-358-8204
- Application Type: Heavy Duty Trucks, Semi-Trucks
- VMRS Code: 016-008-000
- Material: Fiber reinforced rubber bellows
- Air Inlet Inside Thread: 1/4-18 NPT
- Air Inlet Outside Thread: 3/4 16 UNF
- Body Diameter: 10.12 in.
- Bottom Plate Alignment: Parallel
- Bottom Plate Diameter: 9.30 in.
- Bottom Plate Stud: 1/2-13 UNC
- Mounting Stud Configuration – Bottom: 1
- Mounting Stud Configuration – Top: 2
- Piston Height: 2.83 in.
- Piston Material Type: Composite
- Top Plate Diameter: 9.00 in.
- Top Plate Stud: 1/2-13 UNC
- Air Spring Type: 1T Reversible Sleeve
- Collapsed Length: 4.40 in.
- Extended Length: 14.00 in.
- Net Weight: 10.34 lb.
Intended Application
- Compatible with Holland (Neway) Binkley Newlite Rear Air Suspension Systems.
Cross-references
- 1R12508, 1R12522, 3528204, 566CT64456, 64456, 8204, 8484, 90557173, 90557223, 91012P484, AB1DK23H8204, AS8204, FS8204, W013588204, MAF8204, W01-358-8204
