Fortpro Freightliner Torque Rod with Integrated Bushing – Replaces 681-326-6316

Description

Specifications

• Product Line: Suspension
• Category Name: Chassis & Suspension
• Part Type: Rigid Torque Rod
• Alternate Part Name: Torque Rod, Torque Rod Assy, Torque Arm Rigid, Torque Arm with Bushings
• OEM Part Number: 6813266316
• Applicable Bushing: F184208
• Application Type: Semi-Trucks, Heavy Duty Trucks
• Bolt Hole Diameter: 5/8 in.
• Mounting Position: Front Axle Suspension
• Torque Rod Style: Rigid
• Material: Forged Steel
• Bushing Orientation Angle – End 1: 90 deg.
• Bushing Orientation Angle – End 2: 35 deg.
• Bushing Type: Straddle/Bar Pin
• Center Bar Outside Diameter (O.D.): 1-9/16 in.
• Distance Between Bolt Holes: 23 in.
• Net Weight: 11.46 lb.

Bill Of Material

• Torque Rod pcs x 1
• Torque Rod Bush pcs x 2

Intended Application

• Compatible with Freightliner trucks equipped with the Air Ride air suspension system, corresponding to the FAS II configuration.
• Always compare with your OEM part number prior to purchase to confirm full compatibility.

Cross-references

• 16-16749-000, 1616749000, 345-213, 345213, 681-326-6316, 6813266316, E-8808, E8808, GAFF11153, R308808, TMR515
