Description
Specifications
- Product Line: Suspension
- Category Name: Air Springs and Bags
- Part Type: Rolling Lobe Air Spring
- Alternate Part Name: Air Suspension Bag, Reversible Sleeve Air Spring, Rolling Lobe Air Spring, Air Ride Spring, Pneumatic Spring, Suspension Air Bag, Air Bag Suspension
- OEM Part Number: W01-358-9648
- Application Type: Semi-Trucks, Heavy Duty Trucks
- VMRS Code: 016-008-000
- Material: Fiber reinforced rubber bellows
- Air Inlet Inside Thread: 1/4-18 NPT
- Air Inlet Outside Thread: 3/4 16 UNF
- Body Diameter: 10.12 in.
- Bottom Plate Alignment: Parallel
- Bottom Plate Diameter: 10.00 in.
- Bottom Plate Stud: 1/2-13 UNC
- Mounting Stud Configuration – Bottom: 1
- Mounting Stud Configuration – Top: 4
- Piston Height: 4.65 in.
- Piston Material Type: Composite
- Top Plate Diameter: 9.00 in.
- Top Plate Stud: 3/4-10 UNC
- Air Spring Type: 1T Reversible Sleeve
- Collapsed Length: 6.70 in.
- Extended Length: 20.00 in.
- Net Weight: 14.05 lb.
Intended Application
- Compatible with International 9200, 9400, 8100, and LT Series Trucks equipped with Navistar IROS / Air Ride Rear Suspension Systems
Cross-references
- 1R12398, 1R12538, 1R12539, 2027911C1, 2027911C2, 3529648, 566CT73770, 73770, 910175P456, 910S16P1068(BK), 9648, AB1DK23M9648, AS9648, FAS-0695, FAS0695, W013589648, 910S16P1068, W01-358-9648
