Description
Specifications
- Product Line: Steering Components
- Category Name: Power Steering Pump
- Part Type: Steering Pump
- Alternate Part Name: Hydraulic Power Steering Pump
- OEM Part Number: 2106723
- Application Type: Semi-Trucks, Heavy Duty Trucks
- Inlet Port Thread Size: 1-1/16-12 UN-2B
- Mounting Type: 2 Bolt Flange SAE-A SIZE
- Outlet Port Thread Size: 3/14-16 UNF-2B
- Material: Cast Iron
- Max Operating Speed: 3600 rpm
- Max Relief Pressure: 150 bar
- Nominal Flow Rate: 15.0 L/min
- Pump Displacement: 17.5 cm³/rev
- Shaft Rotation Direction: Right-Hand
- Shaft Type: 11-Tooth Spline
- Package Length: 6.00 in.
- Package Width: 8.00 in.
- Package Height: 6.50 in.
- Net Weight: 6.00 lb.
Intended ApplicationCompatible with Freightliner Century Class, FLD, FLD Military and M2 106 with Cummins and Caterpillar C10/C12/NTC/N14 engines with TAS65 and M100 steering gears.
Cross-references
- 1686-653-C91, 1686653C91, 2106723, 3538860-C91, 3538860C91, 542-0065-10, 542006510, A681-466-00K1, A68146600K1, K188-226, K188-280, K188-317, K188226, K188280, K188317
