Description
Specifications
- Product Line: Steering Components
- Category Name: Power Steering Pump
- Part Type: Steering Pump
- Alternate Part Name: Hydraulic Power Steering Pump
- OEM Part Number: 1663204C91
- Application Type: Semi-Trucks, Heavy Duty Trucks
- Inlet Port Thread Size: 1-5/16-12 UN
- Mounting Type: 2 Bolt Flange SAE-A SIZE
- Outlet Port Thread Size: 3/4-16 UNF
- Material: Cast Iron
- Max Operating Speed: 3600 rpm
- Max Relief Pressure: 150 bar
- Nominal Flow Rate: 15.0 L/min
- Pump Displacement: 17.5 cm³/rev
- Shaft Rotation Direction: Right-Hand
- Package Length: 7.00 in.
- Package Width: 8.00 in.
- Package Height: 8.00 in.
- Net Weight: 7.06 lb.
Cross-references
- 14-12464-003, 1412464003, 1663204C91, 451421E, 465.LUK.01, 542-0130-10, 542013010, A-681-466-50K1, A68146650K1, K188-226, K188-280, K188226, K188280
