Fortpro Replacement Air Spring – Compatible with 9622 and 1R11-221 (F245569)

Description

Specifications

• Product Line: Suspension
• Category Name: Air Springs and Bags
• Part Type: Rolling Lobe Air Spring
• Alternate Part Name: Air Bag Suspension, Suspension Air Bag, Pneumatic Spring, Air Suspension Bag, Air Ride Spring, Rolling Lobe Air Spring, Reversible Sleeve Air Spring
• OEM Part Number: W01-358-9622
• Application Type: Semi-Trucks, Heavy Duty Trucks
• VMRS Code: 016-008-000
• Material: Fiber reinforced rubber bellows
• Air Inlet Inside Thread: 1/4-18 NPT
• Body Diameter: 9.12 in.
• Bottom Plate Alignment: Parallel
• Bottom Plate Diameter: 8.50 in.
• Bottom Plate Stud: 1/2-13 UNC
• Mounting Stud Configuration – Bottom: 1
• Mounting Stud Configuration – Top: 1
• Piston Height: 2.80 in.
• Piston Material Type: Steel
• Top Plate Diameter: 9.00 in.
• Air Spring Type: 1T Reversible Sleeve
• Collapsed Length: 4.20 in.
• Extended Length: 12.00 in.
• Net Weight: 16.60 lb.

Intended Application

• Compatible with Kenworth (T600, T800, W900, T660) equipped with AirGlide 100 / AirGlide 200 Rear Air Suspension Systems.

Cross-references

• 1R11221, 3529622, 566CT68359, 68359, 8537, 9622, 999P537(BK), AB1DK20G9622, AS9622, FAS-0698, FAS0698, FS9622, K30319, K30322, W013589622, 999P537, MAF9622, W01-358-9622
