Description
Specifications
- Product Line: Suspension
- Category Name: Air Springs and Bags
- Part Type: Rolling Lobe Air Spring
- Alternate Part Name: Air Bag Suspension, Suspension Air Bag, Pneumatic Spring, Air Suspension Bag, Air Ride Spring, Rolling Lobe Air Spring, Reversible Sleeve Air Spring
- OEM Part Number: W01-358-9039
- Application Type: Semi-Trucks, Heavy Duty Trucks
- VMRS Code: 016-008-000
- Material: Fiber reinforced rubber bellows
- Air Inlet Inside Thread: 1/4-18 NPT
- Air Inlet Outside Thread: 3/4 16 UNF
- Body Diameter: 10.12 in.
- Bottom Plate Alignment: Parallel
- Bottom Plate Diameter: 9.25 in.
- Bottom Plate Stud: 1/2-13 UNC
- Mounting Stud Configuration – Bottom: 1
- Mounting Stud Configuration – Top: 2
- Piston Height: 3.00 in.
- Piston Material Type: Steel
- Top Plate Diameter: 9.00 in.
- Top Plate Stud: 1/2 13 UNC
- Air Spring Type: 1T Reversible Sleeve
- Collapsed Length: 4.40 in.
- Extended Length: 13.50 in.
- Net Weight: 15.25 lb.
Intended Application
- Compatible with Hendrickson (S-Series), Holland (Neway), Hutchens, R & S Truck & Body, Ridewell, FabTek, Sauer, and Watson & Chalin Trailer Air Suspension Systems.
Cross-references
- 101324014, 1013589039C, 101827, 1R12095, 1R12097, 1R12097SA, 1R12122, 1T15K0, 1T15M0, 3048200007, 3090054234, 3090557011, 3090557023, 3130492, 3529039, 554766C1, 566CT64260, 57009039, 64260, 702, 90044199, 90044708, 90054234, 9039, 90557011, 90557023, 90557085, 91010P311, 942401, 942403, AB1DK23F9039, AB1R12095, AB1R12097, AR15171FG, AS0012, AS9039, B11650, B2064, CS112095, CS112097, GY1R12095, H942401, M3511, MNW90557011S,
