Description
Specifications
- Product Line: Suspension
- Category Name: Air Springs and Bags
- Part Type: Rolling Lobe Air Spring
- Alternate Part Name: Air Bag Suspension, Suspension Air Bag, Pneumatic Spring, Air Suspension Bag, Air Ride Spring, Rolling Lobe Air Spring, Reversible Sleeve Air Spring
- OEM Part Number: W01-358-8829
- Application Type: Semi-Trucks, Heavy Duty Trucks
- VMRS Code: 016-008-000
- Material: Fiber reinforced rubber bellows
- Air Inlet Inside Thread: 1/4 NPTF
- Body Diameter: 10.12 in.
- Bottom Plate Alignment: Parallel
- Bottom Plate Diameter: 10.00 in.
- Bottom Plate Stud: 1/2-13 UNC
- Mounting Stud Configuration – Bottom: 1
- Mounting Stud Configuration – Top: 2
- Piston Height: 4.65 in.
- Piston Material Type: Composite
- Top Plate Diameter: 9.00 in.
- Air Spring Type: 1T Reversible Sleeve
- Collapsed Length: 6.70 in.
- Extended Length: 22.00 in.
- Net Weight: 13.75 lb.
Intended Application
- Compatible with Volvo Trucks (Models VNL, VNM, and VNR) equipped with Volvo Air Ride Rear Suspension Systems
Cross-references
- 1R121083, 1R12405, 1R12536, 1R12595, 1R12615, 1S12002, 1S12033, 1S12035, 20413888, 20505399, 3528829, 3934699, 566241010, 566CT74884, 74884, 8079902, 8449, 8829, 91016P449, AB1DF23HP1154, AB1DK23P8829, AS8829, FAS-0728, FAS0728, FS8829, W013588829, MAF8829, W01-358-8829
