Fortpro Double-Convoluted Cab Air Spring – OEM Equivalent to #7136 and 554798C1 (F245646)

Description

Specifications

• Product Line: Suspension
• Category Name: Air Springs and Bags
• Part Type: Double Convoluted Air Spring
• Alternate Part Name: Heavy Duty Suspension Air Bag, Trailer Suspension Air Spring, Rubber Bellows Air Suspension Bag, Double Convoluted Air Spring, Double Convolution Air Bag, Double Bellow Air Spring
• OEM Part Number: W01-358-7136
• Application Type: Heavy Duty Trucks, Semi-Trucks
• VMRS Code: 016-008-000
• Material: Fiber reinforced rubber bellows
• Body Diameter: 14.50 in.
• Bottom Plate Alignment: Parallel
• Bottom Plate C To C Diameter: 6.25 in.
• Bottom Plate Diameter: 11.30 in.
• Bottom Plate Hole Size: 3/8-16 UNC
• Bottom Plate Stud Qty: 4
• Top Plate Air Inlet: 1/4-18 NPTF
• Top Plate C To C Diameter: 6.25 in.
• Top Plate Diameter: 11.30 in.
• Top Plate Stud Qty: 4
• Top Plate Stud Thread Size: 3/8-16 UNC
• Air Spring Type: Double Convoluted
• Collapsed Length: 4.20 in.
• Extended Length: 11.30 in.
• Net Weight: 20.95 lb.

Intended Application

• Compatible Suspension Models: Fargo Trailer, Granning, Hendrickson Trailer, R & S Truck & Body, Ridewell, Watson & Chalin

Cross-references

• 1003587136C, 1027556, 1626, 2B14356, 2B14453, 3130489, 3547136, 4321, 566CT64545, 57007136, 64545, 7136, 9121, AB2B14356, ABSP2B34R7136, AS0004, AS7136, B1080, CS214356, FAS-0775, FAS0775, FD53022321, FS7136, GY2B14356, M3503, M6812, S1080, W013587136, MAF7136, W01-358-7136
