Description
Specifications
- Product Line: Suspension
- Category Name: Chassis & Suspension
- Part Type: Rigid Torque Rod
- Alternate Part Name: Torque Rod, Torque Rod Assy, Torque Arm Rigid, Torque Arm with Bushings
- OEM Part Number: 493921C1
- Applicable Bushing: F174003
- Application Type: Semi-Trucks, Heavy Duty Trucks
- Bolt Hole Diameter: 5/8 in.
- Mounting Position: Rear Suspension
- Torque Rod Style: Rigid
- Material: Forged Steel
- Bushing Orientation Angle – End 1: 0 deg.
- Bushing Orientation Angle – End 2: 15 deg.
- Bushing Type: Straddle/Bar Pin
- Center Bar Outside Diameter (O.D.): 1-1/4 in.
- Distance Between Bolt Holes: 21-31/32 in.
- Net Weight: 20.69 lb.
Bill Of Material
- Torque Rod pcs x 1
- Torque Rod Bush pcs x 2
Intended Application
- Compatible with International Navistar trucks equipped with Corporate Four-Spring Tandem Rear Suspension, designed for single-axle configurations in the 8100 and 9200 Series.
- Always compare with your OEM part number prior to purchase to confirm full compatibility.
Cross-references
- 301305, 345855, 383789, 4852, 493921C1, 57750341, 57750372, 588118C91, 588118C92, 588188C91, E-3789, E3789, R303789, TMR512
